          Stainless Steel Table Top Dough Sheeter with 88" Conveyor Length – 0.75 HP (550 W), 220 V, 1 Phase

          ITEM #: 42154

          MODEL: BE-CN-2083-CSS

          Product Highlights

          Made of high-quality stainless steel; ideal use for long period of time
          Fixed conveyor speed
          Roller adjustments are manual
          Suitable for bakeries, restaurants, and hotels
          Equipped with preset roller thickness control and foldable tables for space-saving storage
          Safety features: safety guards, emergency stop switch, thermal overload device
          • Gross Weight341 lbs.
          • Gross Dimensions38" x 29" x 41"
          • UPC Code690207421540
          • Price LabelPC
          • Country of OriginCHINA
          • CertificationQPS
          • Warranty1 Year Parts and Labor

          Product Overview

          Suitable for bakeries, restaurants, and hotels, Omcan's dough sheeter is designed for optimal performance. Equipped with safety features, preset roller thickness controls, and foldable tables for space saving storage, this machine increases your bakery's production and efficiency. Safe to operate and easy to clean.

          Stainless Steel Table Top Dough Sheeter with 88" Conveyor Length – 0.75 HP (550 W), 220 V, 1 Phase

          ITEM #: 42154

          MODEL: BE-CN-2083-CSS

          Product Highlights

          Made of high-quality stainless steel; ideal use for long period of time
          Fixed conveyor speed
          Roller adjustments are manual
          Suitable for bakeries, restaurants, and hotels
          Equipped with preset roller thickness control and foldable tables for space-saving storage
          Safety features: safety guards, emergency stop switch, thermal overload device

          Product Overview

          Suitable for bakeries, restaurants, and hotels, Omcan's dough sheeter is designed for optimal performance. Equipped with safety features, preset roller thickness controls, and foldable tables for space saving storage, this machine increases your bakery's production and efficiency. Safe to operate and easy to clean.
          • Gross Weight341 lbs.
          • Gross Dimensions38" x 29" x 41"
          • UPC Code690207421540
          • Price LabelPC
          • Country of OriginCHINA
          • CertificationQPS
          • Warranty1 Year Parts and Labor

          Technical Specifications

          Feature

          Specification

          Electrical

          220V / 60Hz / 1Ph

          Power

          0.75 HP / 0.55 kW

          Roller Size

          3.5" (Dia.) x 20.5" (W)

          Roller Adjustable Gap

          1 – 35 mm

          Conveyor Belt Width

          19.75" / 501.7 mm

          Conveyor Width

          22.5" / 571.5 mm

          Conveyor Belt Speed

          18 – 32 m/min

          Roller Speed

          124 r/min

          Maximum Dough Capacity

          11 lbs / 5 kg

          Working Position Dimensions (DWH)

          36" x 88" x 24" / 912 x 2230 x 604 mm

          Resting Position Dimensions (WH)

          32" x 37" / 805 x 930 mm

          Weight

          275.6 lbs / 125 kg
