Technical Specifications

FINISH: Stainless steel hopper, frame lid, and paddle. Tinned bowl, ring, and auger
MOTORS: Auger 10 HP totally enclosed motor. Mixer 5HP totally enclosed (Call for other voltages).
50 Hz available
DRIVE SYSTEMS: Auger-single reduction chain drive (35 pitch-4 row) roller drive chain with tapered roller bearings; Mixer -double reduction gear box and open face gear drive
BOWL TYPE: Size 52, uses size 52 plate and knives
SWITCH: Watertight magnetic switch system with thermal overload protection. Magnetic safety interlocks on hopper lid, includes 12"™ 6-4 power cord.
HOPPER CAPACITY: Up to 400 lbs
OUTPUT CAPACITY: Up to 110 lbs. /minute
STANDARD EQUIPMENT: 35 Degree right hand inlet, stainless steel 2nd grind paddle with center arm, adjustable legs with casters, spurt guard and ring wrench.
OPTIONS: Size 52 plate and knife, electrical or pneumatic footswitch, left hand 35 degree side inlet, left or right 90 degree straight side inlet, hopper with no inlet, connections for tandem operations, continuous feed lid, stainless steel bowl, ring and auger (enterprise or unger).
DIMENSIONS (DWH): 59 5/16" x 35 7/8" x 57 5/16"
