164 QT Heavy-duty Spiral Dough Mixer, 2 Speeds – 2.4kW – 4.5 kW, 208 V, 3 Phase
Be the first to rate 164 QT Heavy-duty Spiral Dough Mixer, 2 Speeds – 2.4kW – 4.5 kW, 208 V, 3 Phase![](https://omcan.com/wp-content/uploads/2017/11/share.png)
Item: 49123
Model: MX-IT-0100-M
UPC CODE
690207491239
WARRANTY
1 Year Parts and Labor
CERTIFICATIONS
cETLus, ETL Sanitation
COUNTRY OF ORIGIN
ITALY
SHIPPED BY FREIGHT
YES
GROSS WEIGHT
992 LBS
GROSS DIMENSIONS
48.4 x 29.1 x 49.2 IN
TYPE OF PLUG
NEMA 5-15 P
PRODUCT OVERVIEW
Heavy-duty spiral mixers make preparing of dough possible with ease and efficiency.
This heavy-duty spiral machine with fixed stainless steel basins includes a rear basin guard. It is equipped with two kneading speeds, two timers to program the working cycle, two fixed wheels, and adjustable feet for easy positioning.
FEATURES:
• Intuitive Interface
You can access all functions with a few simple actions: two work speeds, two times, and an automatic cycle.
• Bowl & Spiral
Both are made from high-resistance stainless steel. The design, dimensions, and sizing have all been carefully devised to ensure a peerless finished product.
• Stunning Dough
Designed to help you create a dough with perfect, handmade consistency. The Plus version has a reinforced spiral drive mechanism specially designed for dryer dough mixes.
• Highly Safe
The protective grill in stainless steel is ergonomically designed and completely safe. When opened the machine automatically stops working.
• Solid Stability
The feet give the machine great stability, while the wheels mean that the machine can be moved easily to clean the workspace.
• User-friendly At All Times
A special button means you can respond to emergencies quickly, following the regulations out there.
This heavy-duty spiral machine with fixed stainless steel basins includes a rear basin guard. It is equipped with two kneading speeds, two timers to program the working cycle, two fixed wheels, and adjustable feet for easy positioning.
FEATURES:
• Intuitive Interface
You can access all functions with a few simple actions: two work speeds, two times, and an automatic cycle.
• Bowl & Spiral
Both are made from high-resistance stainless steel. The design, dimensions, and sizing have all been carefully devised to ensure a peerless finished product.
• Stunning Dough
Designed to help you create a dough with perfect, handmade consistency. The Plus version has a reinforced spiral drive mechanism specially designed for dryer dough mixes.
• Highly Safe
The protective grill in stainless steel is ergonomically designed and completely safe. When opened the machine automatically stops working.
• Solid Stability
The feet give the machine great stability, while the wheels mean that the machine can be moved easily to clean the workspace.
• User-friendly At All Times
A special button means you can respond to emergencies quickly, following the regulations out there.
Bowl Capacity: 164 QT
Max Dry Flour Capacity: 138 lb. (63 kg.)
Max Dough Capacity: 220 lb. (100 kg.)
Timer: 2
RPM: 2
Wattage: Spiral: 2,400 W / 4,400 W | Bowl: 5,600 W
Power: Spiral: 2,400 – 4,500 W | Bowl: 560 W
Amps: Spiral: 8.3 A – 15.26 A | Bowl: 19.4 A
Electrical: 208V / 60Hz / 3Ph
Bowl Dimensions (diaH): 27.6″ x 16.1” (701 x 361 mm)
Net Weight: 992.1 lb. (450 kg.)
Net Dimensions (DWH): 29.1” 48” x 49.2” (740 x 1220 x 1250mm)
Gross Weight: 992 lb. (450 kg.)
Gross Dimensions (DWH): 29” x 48” x 49” (740 x 1230 x 1250 mm)
Max Dry Flour Capacity: 138 lb. (63 kg.)
Max Dough Capacity: 220 lb. (100 kg.)
Timer: 2
RPM: 2
Wattage: Spiral: 2,400 W / 4,400 W | Bowl: 5,600 W
Power: Spiral: 2,400 – 4,500 W | Bowl: 560 W
Amps: Spiral: 8.3 A – 15.26 A | Bowl: 19.4 A
Electrical: 208V / 60Hz / 3Ph
Bowl Dimensions (diaH): 27.6″ x 16.1” (701 x 361 mm)
Net Weight: 992.1 lb. (450 kg.)
Net Dimensions (DWH): 29.1” 48” x 49.2” (740 x 1220 x 1250mm)
Gross Weight: 992 lb. (450 kg.)
Gross Dimensions (DWH): 29” x 48” x 49” (740 x 1230 x 1250 mm)
