          24 Qt. Heavy-duty Spiral Dough Mixer, 2 speed – 208V, 1.5HP/1HP, 3Ph

          ITEM #: 13166

          MODEL: MX-IT-0020-T

          • Gross Weight175 lbs.
          • Gross Dimensions29" x 17" x 29"
          • UPC Code690207131661
          • Price LabelPC
          • Type of PlugNEMA L15-20P
          • Country of OriginITALY
          • Warranty1 Year Parts and Labor

          Product Overview

          Your next commercial application for handling large batches with ease.

          This dough mixer features robust, fixed stainless steel high-strength spirals and is capable of handling substantial flour and dough capacities. Whether you’re preparing pizza, cookies, or bread, you’ll see a significant boost in kitchen efficiency once this mixer becomes part of your setup.

          FEATURES:
          • Easy to use Control
          • Grated Lid for Safety
          • Made of stainless steel
          • Fixed stainless steel high-strength spirals
          • Safety device that stops the machine when the bowl cover is lifted
          • Greatly reduce the usual mixing time of traditional machines
          • Ideal for bakeries and pizza shops, these mixers perform well with both hard and soft dough

          24 Qt. Heavy-duty Spiral Dough Mixer, 2 speed – 208V, 1.5HP/1HP, 3Ph

          ITEM #: 13166

          MODEL: MX-IT-0020-T

          Product Overview

          Your next commercial application for handling large batches with ease.

          This dough mixer features robust, fixed stainless steel high-strength spirals and is capable of handling substantial flour and dough capacities. Whether you’re preparing pizza, cookies, or bread, you’ll see a significant boost in kitchen efficiency once this mixer becomes part of your setup.

          FEATURES:
          • Easy to use Control
          • Grated Lid for Safety
          • Made of stainless steel
          • Fixed stainless steel high-strength spirals
          • Safety device that stops the machine when the bowl cover is lifted
          • Greatly reduce the usual mixing time of traditional machines
          • Ideal for bakeries and pizza shops, these mixers perform well with both hard and soft dough
          • Gross Weight175 lbs.
          • Gross Dimensions29" x 17" x 29"
          • UPC Code690207131661
          • Price LabelPC
          • Type of PlugNEMA L15-20P
          • Country of OriginITALY
          • Warranty1 Year Parts and Labor

          Technical Specifications

          Feature

          Specification

          Bowl Capacity

          24 QT

          Max Dry Flour Capacity

          24 lb. / 11 kg

          Max Dough Capacity

          40 lb. / 17 kg

          Bowl RPM

          1st Speed - 6 | 2nd Speed - 12

          Spiral RPM

          1st Speed - 60 | 2nd Speed - 120

          Power

          1.5 / 1 hp | 1100 / 750 W

          Amps

          3.8 | 2.6 A

          Electrical

          208V / 60Hz / 3Ph

          Bowl Dimensions (diaH)

          Ø 14.4” x 9.64” (366 x 245 mm)

          Net Weight

          161 lb. / 73 kg

          Net Dimensions (WDH)

          27” x 15.4” x 26.4” (686 x 391 x 671 mm)
