40-45 lb. Tube-Fired Liquid Propane Gas Floor Fryer – 120,000 BTU
Product Highlights
Tube heat exchange design - Faster temperature recovery and superior efficiency
4-Tube model with a total power of 120,000 BTU/hr
Temperature control range - 200°F - 400°F (93°C - 205°C)
High-limit temperature protection at 450°F (232°C), with automatic gas cutoff
Four adjustable stainless steel legs
Twin basket with plastic-coated handles included
Snap-action millivolt thermostat behind the door - no electric connection required
1 1/4” full port drain valve for fast and complete oil drainage
- Gross Weight156 lbs.
- Gross Dimensions16.5" x 32.3" x 33.5"
- UPC Code690207486372
- Price LabelPC
- Country of OriginChina
- CertificationcCSAus, CSA
- Warranty1 Year Parts and Labor
Product Overview
Omcan Tube-Fired Liquid Propane Gas Fryer – 120,000 BTU, 4-Tube Design
Engineered for performance and reliability, this heavy-duty gas fryer is built for busy commercial kitchens. Its tube heat exchange design delivers fast temperature recovery and superior efficiency, while a large cold zone helps capture food particles and extend oil life.
The stainless steel fry tanks are pressure-blasted (peened) for a smooth finish and easy cleaning.
Key Features
4-tube heat exchanger delivering 120,000 BTU/h total heat power
Snap-action millivolt thermostat behind the door — no electrical connection required
Temperature range: 200°F – 400°F (93°C – 205°C)
Over-temperature protection at 450°F (232°C) — gas shuts off automatically if oil overheats
Four stainless steel adjustable legs
Twin fry baskets with plastic-coated handles
Suitable for high-sediment food like breaded items
40-45 lb. Tube-Fired Liquid Propane Gas Floor Fryer – 120,000 BTU
Product Highlights
Tube heat exchange design - Faster temperature recovery and superior efficiency
4-Tube model with a total power of 120,000 BTU/hr
Temperature control range - 200°F - 400°F (93°C - 205°C)
High-limit temperature protection at 450°F (232°C), with automatic gas cutoff
Four adjustable stainless steel legs
Twin basket with plastic-coated handles included
Snap-action millivolt thermostat behind the door - no electric connection required
1 1/4” full port drain valve for fast and complete oil drainage
Product Overview
Omcan Tube-Fired Liquid Propane Gas Fryer – 120,000 BTU, 4-Tube Design
Engineered for performance and reliability, this heavy-duty gas fryer is built for busy commercial kitchens. Its tube heat exchange design delivers fast temperature recovery and superior efficiency, while a large cold zone helps capture food particles and extend oil life.
The stainless steel fry tanks are pressure-blasted (peened) for a smooth finish and easy cleaning.
Key Features
4-tube heat exchanger delivering 120,000 BTU/h total heat power
Snap-action millivolt thermostat behind the door — no electrical connection required
Temperature range: 200°F – 400°F (93°C – 205°C)
Over-temperature protection at 450°F (232°C) — gas shuts off automatically if oil overheats
Four stainless steel adjustable legs
Twin fry baskets with plastic-coated handles
Suitable for high-sediment food like breaded items
- Gross Weight156 lbs.
- Gross Dimensions16.5" x 32.3" x 33.5"
- UPC Code690207486372
- Price LabelPC
- Country of OriginChina
- CertificationcCSAus, CSA
- Warranty1 Year Parts and Labor
Technical Specifications
Gas Type | Liquid Propane Gas |
Fryer Type | Tube-Fired; Floor Model |
Number of Burners | 4 |
Thermal Power | 120,000 BTU/hr |
Oil Capacity | 40 - 45 lbs. (20 - 23 L) |
Net Dimensions | 15 5" x 31.3" x 45.3" |
Net Weight | 138.6 lbs. (62.9 kgs.) |
Packaging Dimensions | 16.5" x 32.3" x 33.5" |
Packaging Weight | 156 lbs. (70.8 kgs.) |
